MTS-MONO-ME 3.12

National Registry Number 89778-23

Portable test system

The MTS-MONO-ME 3.12 is a compact portable test system designed for accuracy testing/verification/calibration of smart energy meters and measuring transducers.

It combines three instruments in one: a reference meter, a current and voltage source and a volt-mA calibrator/error calculator.

Accuracy class: 0.05

Purpose

The MTS-MONO-ME 3.12 is intended for verification and calibration of:

	Smart energy meters with power quality measurement function (class 0.2S) Test scheme
	Measuring transducers with unified DC current and voltage signals Test scheme

Application

The MTS-MONO can be used both in the laboratory and field conditions.

With the MTS-Service software, testing is performed automatically including generation of test reports (complete with environmental data according to ISO/IEC 17025-2009 as well).

Basic technical data

Parameter	Range	Measurement error
Voltage Ranges: Unom = 60, 120, 240 V	6 ... 288 V	% of reference ±0.03 % + ∆
Current Ranges: Inom = 0,05; 0,1; 0,25; 0,5; 1; 2,5; 5; 10 A	5 mA ... 12 A	% of reference ±0.03 % + ∆
Frequency	40 ... 70 Hz	Absolute ±0.002 Hz
Phase angle	–180° ... +180°	Absolute ±0.03°
Power factor	–0.1 ... +0.1	Absolute ±0.005
Active power	0.01Unom ... 1.5Unom 0.1Inom ... 1.5Inom	% of reference ±0.05 % + ∆

∆: additional error

Parameter	Output setting range	In increments of	Value
Voltage Ranges: Unom = 60/220 V Distortion Max output power per phase	20 ... 300 V	0.1 V	≤1 % 30 VA
Current Ranges: Inom = 1, 10 A Distortion Max output power per phase	1 mA ... 12 A	1 mA	≤1 % 60 VA
Frequency	45 ... 70 Hz	0.01 Hz
Phase angle	–180° ... +180°	±0.01°
Voltage and current harmonic composition Harmonics Interharmonics	2 ... 50 0.5 ... 50.5

Parameter	Range	Measurement error
Input		% of reference
DC voltage	&–15...+15 V 0...15 V	±0.03 %
DC current	–7.5...+7.5 mA From -30 to 30	±0.05 %
Output		Absolute
DC voltage	–10.5...+10.5 V	±0.002 V
Current	–24...+24 mA	±0.005 mA

Parameter	Input	Output
Pulse level	5 ... 15 V	5 V
Frequency (max)	36 kHz	18 kHz
Pulse duration	>14 µs	10 ± 2 µs
Constant	1 ... 999 999 999 pulse/(kW • h)	C = 144 • 108/(Inom • Unom) pulse/(W • h)

AC power consumption

400 VA, or less

Mains supply

195 ... 253 V
47 ... 63 Hz

Operating temperature range

от +10 до +35 °С

Weight

16 kg,or less

Benefits

	Compact size (3 instruments in one unit)
	PC with MTS-Service software installed (serves for automatic control of test procedures and generation of test reports) is included in the standard supply
	Meter connection time is minimized
